Features
65K BTU THRESHOLD
Compatible with most 36- or 30-inch cooktops, including some commercial-style cooking surfaces.
4-SPEED ELECTRONIC TOUCH CONTROL WITH LED DISPLAY
Provides sleek, visual confirmation of your ventilation selections, settings, and filter status.
5-MINUTE BOOST FUNCTION
Enhances performance when using high-temperature cooking techniques by providing a timed, short burst of high-speed ventilation to effectively remove steam, grease, and odors from the air.
Specifications
General
Blower Included
Yes
Airflow
330 CFM
Style
Slide-Out
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Under-Cabinet
Features
Wi-Fi
No
Ducting Information
6" Round Vertical Duct Direction
Speeds
Sones with High Speed: 4
Additional Information
• 65K BTU Threshold
• Two LED Lights
• Venting: Exterior or Recirculating
• Auto On Function
• Flush to Cabinetry
• 5-Minute Boost Function
• Centrifugal Blower
• Two LED Lights
• Venting: Exterior or Recirculating
• Auto On Function
• Flush to Cabinetry
• 5-Minute Boost Function
• Centrifugal Blower
Certifications and Approvals
Energy Star Certified
No
Dimensions
Class Width
36"
Width
36 inch(es) / 91.44 cm
Height
32 inch(es) / 81.28 cm
Depth
11 inch(es) / 27.94 cm
Weight
36.2 lb(s) / 16.42 kg
Additional Dimensions
• Cutout Depth: 22.86 cm, 9.0"
• Cutout Height: 38.10 cm, 15.0"
• Cutout Height: 38.10 cm, 15.0"
Shipping Dimensions
Width
39.37 inch(es) / 100.01 cm
Height
15.13 inch(es) / 38.42 cm
Depth
17.25 inch(es) / 43.82 cm
Weight
41.01 lb(s) / 18.6 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
883049547534
